Low Voltage Switchboards
Our UL-891 listed Low Voltage Switchboards deliver reliable power distribution up to 4,000A with short circuit protection up to 100kA at 480V. Each switchboard features a fully rated silver-plated copper bus or tin-plated aluminum bus, modular construction, and fixed-mount or draw-out breakers. It handles 600VAC or 250VDC systems with neutral ratings up to 200% for 4-wire configurations.
Available in Type 1 or 3R enclosures with multi-door vault options and custom skid-mounted configurations, our switchboards integrate panelboards, automatic transfer switches, surge protection, transformers, motor starters, PLCs, and comprehensive metering systems. Every unit receives factory function testing and ships ready for indoor or outdoor deployment. MCI Power Products & Controls Solutions delivers the customization, durability, and ANSI/IEEE/NEMA compliant protection your facility demands.
Write a Review
Low Voltage Switchboards
High-Capacity LV Switchboards — Up to 4000A, Fully Rated Bus
Engineered by MCI Power Products & Controls Solutions for ultimate flexibility and resilience. Our UL 891 listed switchboards deliver fully rated bus systems (1000A/sq in. copper, 750A/sq in. aluminum) in modular configurations up to 4000A with 100kA short-circuit protection and multi-door vault accessibility for maximum safety and serviceability.
Configure fixed-mount or draw-out breakers, integrate panelboards, ATS, transformers, motor starters, PLCs, and comprehensive metering within NEMA 1 or 3R enclosures with front, rear, side, or top accessibility. Factory-tested and UL 891/cUL compliant with skid-mountable options available.
Configurable LV Switchboards — Front/Rear Access, Top/Bottom Entry
MCI Power Products & Controls Solutions delivers UL 891 switchboards with unmatched flexibility. Configure main lug or main breaker, fixed-mount or draw-out breakers, split/dual mains, and choose front, rear, side, or top accessibility with top/bottom cable or bus-duct entry. Build your ideal power distribution system with modular sections up to 4000A and 100kA protection.
Access & Entry Flexibility
Design for your space and workflow with front, rear, side, or top access configurations. Choose top or bottom cable entry, bus-duct connections, or combination setups. Multi-door vault options provide enhanced safety and independent access to sections. Available as freestanding, wall-mounted, or custom skid-mounted units for housed or unhoused applications.
System Configuration Options
Build main lug only, main breaker, or service-entrance rated systems. Configure split or dual mains, tie breakers, and sectioned lineups to match your distribution strategy. Select fixed-mount or draw-out breakers for mains and feeders. Integrate panelboards, ATS, transformers, motor starters, PLCs, metering, and monitoring—all within a single, coordinated enclosure.
Bus & Breaker Configurations
Specify silver-plated copper bus (1000A/sq in.) or tin-plated aluminum bus (750A/sq in.) with fully rated systems up to 4000A, 600VAC. Choose thermal magnetic or electronic circuit breakers with 80% or 100% ratings, standard or high kAIC values. NEMA 1 or 3R enclosures in carbon steel, aluminum, or stainless steel. Factory-tested and UL 891 / cUL listed.
UL 891 Low Voltage Switchboards — Technical Specifications
- Certification UL 891 Listed, cUL available; built to ANSI/IEEE/NEMA
- System Voltage Up to 600 VAC, 3-phase; 3- or 4-wire (neutral up to 200%)
- Ampere Rating Up to 4000 A (fully rated bus)
- Short-Circuit Rating (SCCR) Up to 100 kA @ 480 V
- Main Configuration Main Lug Only (MLO) or Main Breaker (MB); Service Entrance options
- Bus System Copper or aluminum bus; optional tin/silver plating; full-length ground & neutral
- Enclosure NEMA 1 (indoor) or NEMA 3R (outdoor); optional climate control
- Access & Cable Entry Front and/or rear access; top/bottom cable entry; bus duct provisions
- Lineup Options Split/dual mains, tie breakers, sectionalized lineups
- Integrated Equipment Panelboards, ATS, SPDs, distribution transformers, motor starters
- Controls & Automation PLC/controls, metering, advanced monitoring; Modbus/Ethernet options
- Protection & Metering Surge protection, revenue-grade metering, protective relays (as specified)
- Finish & Construction Factory-powder-coated steel; utility color options available
- Factory Testing Fully assembled, inspected, and function-tested prior to shipment
- Applications Industrial facilities, utilities, oil & gas, data centers, commercial buildings
- Manufactured By MCI Power Products & Controls Solutions Group
Ready to Configure Your
UL 891 Low Voltage Switchboard?
Build a switchboard lineup tailored to your site and utility requirements. Up to 4000 A at 600 VAC, short-circuit ratings to 100 kA @ 480 V, and NEMA 1 / 3R construction. Main Lug or Main Breaker, service-entrance options, copper or aluminum bus, top/bottom entry with front or rear access—integrated panelboards, ATS, SPDs, transformers, PLC/controls, and metering.
