Variable Speed Drive Panel (VSDP)
Our Variable Speed Drive Panel (VSDP) delivers industrial-grade motor control from 10HP to 800HP in NEMA 3R rated, UL508a listed enclosures built to withstand the harshest environments. Featuring premium Schneider ATV630 and LS H-100 variable frequency drives, each turnkey system arrives ready to install with comprehensive electrical protection, door-mounted keypads, and intuitive Hand-Off-Auto controls.
Write a Review
Variable Speed Drive Panel (VSDP)
Outdoor-Rated, Turnkey Motor Control
Industrial motors face rain, dust, temperature extremes, and corrosive environments that destroy unprotected electronics. The MCI Power Products & Controls Solutions Variable Speed Drive Package delivers NEMA 3R rated protection with premium Schneider ATV630 and LS H-100 VFDs from 10HP to 800HP—factory-assembled, wired, and tested so your motors run efficiently from day one.
Each turnkey system arrives with integrated surge protection, line reactors, door-mounted keypads, and Hand-Off-Auto controls—eliminating field wiring risks and commissioning delays. Optimize energy by matching motor speed to load demands while extending equipment life. Deploy reliable control where the environment is harshest and uptime matters most.
Engineered for Performance and Reliability
Motor failures cost thousands per hour in lost production, emergency repairs, and damaged equipment. The MCI Variable Speed Drive Package eliminates these risks through industrial-grade protection, precise control, and factory-tested integration—delivering years of efficient operation in the harshest environments.
Protection Against Failure
NEMA 3R rated enclosures shield electronics from rain, dust, and temperature extremes. UL508a listed with 480V breakers, surge protection, and line reactors guard against transients and harmonics—preventing the costly breakdowns and emergency repairs that halt production.
Precision Control, Maximum Efficiency
Schneider ATV630 and LS H-100 VFDs (10HP to 800HP) match motor output to load demands—cutting energy consumption up to 50%. Door-mounted keypads and Ethernet connectivity enable remote monitoring. Soft-start eliminates mechanical shock and extends equipment life.
Factory-Integrated Reliability
Every component—transformers, potentiometers, lights, Hand-Off-Auto switches—arrives factory-assembled, wired, and tested. No field wiring errors, no compatibility issues, no delays. VFD fault indication provides instant diagnostics for rapid troubleshooting.
VSDP Technical Specifications
- Drive Manufacturers Schneider ATV630, LS H-100
- Power Range 10HP to 800HP
- Voltage Rating 480V (3-Phase)
- Enclosure Rating NEMA 3R, UL508a Listed
- Main Disconnect 480V Circuit Breaker (Standard)
- Control Power 480:120V Transformer / 750VA (Standard)
- Line Protection 3% Line Reactor, Surge Protector (Standard)
- VFD Interface Door-Mounted Keypad (Standard), Ethernet Module (Optional)
- Control Features Speed Potentiometer, Hand-Off-Auto Switch, VFD Fault Reset (Standard)
- Status Indicators VFD Running Light (Green), Fault Indicator (Red) (Standard)
- Ventilation Filtered Cooling Fan with Air Intake (Standard)
- Optional Components 5% Load Reactor, DV/DT Filter, 12" Leg Kit, Enclosure Heater, Main Power Indicator
- Industry Applications Industrial Automation, Energy & Utilities, Oil & Gas, Agriculture, Building Services
- Available Enclosure Frames Frame 1 through Frame 8 (See Technical Drawings)
Ready to Configure Your Drive Package?
Get a custom VSDP solution tailored to your exact power requirements. From 10HP to 800HP with premium Schneider or LS drives, NEMA 3R protection, and complete system integration—we'll engineer the perfect fit for your operation.
